Item Component Spare part number
(1) Display assembly: The display assembly is spared at the subcomponent level only. For more display assembly spare part
information, see Display assembly components on page 18.
(2) Top cover with keyboard
Non-backlit keyboard, includes ngerprint reader, pike silver L37530-xx1
Backlit keyboard, includes ngerprint reader, pike silver L37531-xx1
Non-backlit keyboard, no ngerprint reader, pike silver L37533-xx1
Backlit keyboard, no ngerprint reader, pike silver L37534-xx1
Backlit keyboard, includes ngerprint reader, mineral silver (-001 United States only) L37532-xx1
(3) TouchPad
NOTE: The TouchPad cable is available using spare part number L37375-001.
Pike silver L38040-001
Mineral silver L38043-001
(4) TouchPad bracket included in TouchPad spare
kit
(5) Fingerprint reader (includes bracket)
Pike silver models L37373-001
Mineral silver models L38041-001
(6) Power connector cable
NOTE: The power connector cable Mylar light cover is available using spare part number
L45223-001.
L37358-001
(7) Speaker Kit (includes cable) L37374-001
(8) USB board
NOTE: The USB board cable is available using spare part number L37371-001.
L37372-001
(9) System board (includes processor and replacement thermal material):
Intel Core i7-8565U processor, 8 GB of system memory, ngerprint reader L37351-xx1
Intel Core i5-8265U processor, 8 GB of system memory, ngerprint reader L37350-xx1
Intel Core i5-8265U processor, 8 GB of system memory, no ngerprint reader L37349-xx1
Intel Core i5-8265U processor, 4 GB of system memory, ngerprint reader L37348-xx1
Intel Core i3-8145U processor, 8 GB of system memory, ngerprint reader L42277-xx1
Intel Core i3-8145U processor, 4 GB of system memory, ngerprint reader L37347-xx1
(10) Heat sink (includes replacement thermal material): L37377-001
(11) Fan (includes cable) L37376-001
(12) WLAN module:
Realtek RTL8822BE 802.11ac 2×2 WiFi + Bluetooth 4.2 (MU-MIMO supported) 924813-855
Intel Wireless-AC 9560 802.11ac 2×2 WiFi + Bluetooth5 (non-vPro) (MU-MIMO, Gigabit WiFi
speeds supported)
L22634-005
16 Chapter 3 Illustrated parts catalog
