Battery
Description Spare part number
2-cell, 37-WHr, 4.96-AHr, Li-ion battery L28076-005
Before removing the battery, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 25).
Remove the battery:
1. Disconnect the battery cable from the system board (1).
2. Remove the six Phillips M2.0×2.5 screws (2) that secure the battery to the computer.
3. Lift the inside of the battery, and then remove the battery from the computer (3).
TIP: When installing the battery, make sure to route the cable in the clips near the top of the battery
(4).
Reverse this procedure to install the battery.
Component replacement procedures 27
