10 Windows 8.1 – Backing up, restoring, and
recovering
This chapter provides information about the following processes:
Creating recovery media and backups
Restoring and recovering your system
Creating recovery media and backups
1. After you successfully set up the computer, create HP Recovery media. This step creates a
backup of the HP Recovery partition on the computer. The backup can be used to reinstall the
original operating system in cases where the hard drive is corrupted or has been replaced.
HP Recovery media you create will provide the following recovery options:
System Recovery—Reinstalls the original operating system and the programs that were
installed at the factory.
Minimized Image Recovery—Reinstalls the operating system and all hardware-related
drivers and software, but not other software applications.
Factory Reset—Restores the computer to its original factory state by deleting all
information from the hard drive and re-creating the partitions. Then it reinstalls the
operating system and the software that was installed at the factory.
See
Creating HP Recovery media on page 136.
2. Use the Windows tools to create system restore points and create backups of personal
information. For more information and steps, see Help and Support. From the Start screen, type
help, and then select Help and Support.
Creating HP Recovery media
HP Recovery Manager is a software program that offers a way to create recovery media after you
successfully set up the computer. HP Recovery media can be used to perform system recovery if the
hard drive becomes corrupted. System recovery reinstalls the original operating system and the
software programs installed at the factory, and then configures the settings for the programs. HP
Recovery media can also be used to customize the system or restore the factory image if you replace
the hard drive.
Only one set of HP Recovery media can be created. Handle these recovery tools carefully, and
keep them in a safe place.
HP Recovery Manager examines the computer and determines the required storage capacity for
the blank USB flash drive or the number of blank DVD discs that will be required.
To create recovery discs, your computer must have an optical drive with DVD writer capability,
and you must use only high-quality blank DVD-R, DVD+R, DVD-R DL, or DVD+R DL discs. Do
not use rewritable discs such as CD±RW, DVD±RW, double-layer DVD±RW, or BD-RE
(rewritable Blu-ray) discs; they are not compatible with HP Recovery Manager software. Or
instead you can use a high-quality blank USB flash drive.
136 Chapter 10 Windows 8.1 – Backing up, restoring, and recovering

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Pavilion 15 and is the answer not in the manual?

HP Pavilion 15 Specifications

General IconGeneral
Form factorClamshell
Product typeLaptop
Product colorBlack
Country of originChina
Bus typeDMI2
SteppingC0
Tjunction100 °C
Processor cache3 MB
Processor cores2
Processor modeli5-4200U
System bus rate- GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-4200 Mobile series
Processor socketBGA 1168
Processor threads4
Processor codenameHaswell
Processor frequency1.6 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency2.6 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x4, 2x4
Thermal Design Power (TDP)15 W
Maximum number of PCI Express lanes12
AccelerometerYes
Motherboard chipset-
Memory slots2x SO-DIMM
Internal memory4 GB
Memory clock speed1600 MHz
Internal memory typeDDR3L-SDRAM
Maximum internal memory- GB
Memory layout (slots x size)1 x 4 GB
HDD speed5400 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Total storage capacity500 GB
Compatible memory cardsSD
Number of HDDs installed1
HD typeNot supported
Display surfaceGloss
Display diagonal15.6 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
On-board graphics card ID0xA16
Discrete graphics card modelAMD Radeon HD 8670M
On-board graphics card modelIntel® HD Graphics 4400
Discrete graphics memory typeGDDR3
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory1.74 GB
On-board graphics card base frequency200 MHz
On-board graphics card dynamic frequency (max)1000 MHz
Audio systemDTS Sound+
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates10, 100 Mbit/s
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity0
Pointing deviceTouchpad
Operating system installedUbuntu Linux
Processor codeSR170
Processor ARK ID75459
Intel TSX-NI version0.00
Processor package size40 x 24 x 1.5 mm
Intel ME Firmware Version9.5
Supported instruction setsAVX 2.0
Intel Smart Connect Technology version1.00
Battery life (max)- h
AC adapter power65 W
Weight and Dimensions IconWeight and Dimensions
Depth258 mm
Width385.6 mm
Height22.6 mm
Weight2330 g
