Item Component Spare part number

Vibrant red finish 766894-001

Neon purple finish 777222-001

For HP Pavilion 15 Notebook PC

Optical drive, DVD+/-RW DL SuperMulti (includes optical drive hardware kit with

optical drive bezel and bracket):

762503-001

Blu-ray Disc R/RW with SuperMulti for AMD models only 778266-001

Optical drive board natural silver 778856-001

Optical drive hardware kit for touchscreen Intel computer models 790019-001

Miscellaneous parts

Component Spare part number

AC adapter:

45 W HP Smart AC adapter (nPFC, RC, 3-wire, 4.5 mm, nslim) 741727-001

65 W HP Smart AC adapter (nPFC, RC, 3-wire, 4.5 mm) 710412-001

90 W HP Smart AC adapter (PFC, RC, 3-wire, 4.5 mm), for use with computer models with AMD

processors

710413-001

90-W AC adapter (EM, PFC, SMT, 3-wire, 4.5-mm) for use with HP Pavilion 15 Notebook PC

computer models only

710414-001

65-W HP Smart AC adapter (non-PFC, EM, 3-wire, 4.5-mm) for use with HP Pavilion 15

Notebook PC computer models only

714657-001

Power cord (3 pin, black, 1.0 m):

For use in North America 755530-001

For use in Argentina 755530-D01

For use in Australia, for use with computer models with Intel processors 755530-011

For use in Brazil, for use with computer models with Intel processors 755530-202

For use in Europe, for use with computer models with Intel processors 755530-021

For use in India, for use with computer models with Intel processors 755530-D61

For use in Italy 755530-061

For use in the People's Republic of China, for use with computer models with Intel processors 755530-AA1

For use in South Korea, for use with computer models with Intel processors 755530-AD1

For use in Taiwan, for use with computer models with Intel processors 755530-AB1

For use in Thailand, for use with computer models with Intel processors 755530-201

For use in the United Kingdom and Singapore, for use with computer models with Intel

processors

755530-031

For use in Denmark, Finland, Norway 755530-081

44 Chapter 3 Illustrated parts catalog
