Base enclosure
Description Spare part number
Top cover for HP Pavilion 15 Notebook PC computer models:
With full size textured island-style Keyboard. Touchpad and numeric keypad black for use in the
United States
762529-001
With full size textured island-style Keyboard and numeric keypad black for use in the United
Kingdom
762529-031
With full size textured island-style Keyboard and numeric keypad black for use in Germany 762529-041
With full size textured island-style Keyboard and numeric keypad black for use in France 762529-051
With full size textured island-style Keyboard and numeric keypad black for use in Italy 762529-061
With full size textured island-style Keyboard and numeric keypad black for use in Spain 762529-071
With full size textured island-style Keyboard and numeric keypad black for use in Portugal 762529-131
With full size textured island-style Keyboard and numeric keypad black for use in Turkey 762529-141
With full size textured island-style Keyboard and numeric keypad black for use in Greece 762529-151
With full size textured island-style Keyboard and numeric keypad black for use in Latin America 762529-161
With full size textured island-style Keyboard and numeric keypad black for use in Saudi Arabia 762529-171
With full size textured island-style Keyboard and numeric keypad black for use in Hungary 762529-211
With full size textured island-style Keyboard and numeric keypad black for use in Russia 762529-251
With full size textured island-style Keyboard and numeric keypad black for use in Bulgaria 762529-261
With full size textured island-style Keyboard and numeric keypad black for use in Romania 762529-271
With full size textured island-style Keyboard and numeric keypad black for use in Thailand 762529-281
With full size textured island-style Keyboard and numeric keypad black for use in Japan 762529-291
With full size textured island-style Keyboard and numeric keypad black for use in Europe 762529-A41
With full size textured island-style Keyboard and numeric keypad black for use in Taiwan 762529-AB1
With full size textured island-style Keyboard and numeric keypad black for use in South Korea 762529-AD1
With full size textured island-style Keyboard and numeric keypad black for International use 762529-B31
With full size textured island-style Keyboard and numeric keypad black for use in the Adriatics 762529-BA1
With full size textured island-style Keyboard and numeric keypad black for use in Israel 762529-BB1
With full size textured island-style Keyboard and numeric keypad black for use in Switzerland 762529-BG1
With full size textured island-style Keyboard and numeric keypad black Canada 762529-DB1
With full size textured island-style Keyboard and numeric keypad black for use in the
Netherlands
762529-DH1
With full size textured island-style Keyboard and numeric keypad black for use in Czech and
Slovackia
762529-FL1
With full size textured island-style Keyboard and numeric keypad black for use in South Africa 762529-FP1
With full size textured island-style Keyboard, TouchPad, and numeric keypad white for use in the
United States
762530-001
80 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

HP Pavilion 15 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Country of origin	China
Bus type	DMI2
Stepping	C0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-4200U
System bus rate	- GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4200 Mobile series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Haswell
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.6 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x4, 2x4
Thermal Design Power (TDP)	15 W
Maximum number of PCI Express lanes	12
Accelerometer	Yes
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 4 GB
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
HD type	Not supported
Display surface	Gloss
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0xA16
Discrete graphics card model	AMD Radeon HD 8670M
On-board graphics card model	Intel® HD Graphics 4400
Discrete graphics memory type	GDDR3
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	200 MHz
On-board graphics card dynamic frequency (max)	1000 MHz
Audio system	DTS Sound+
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Pointing device	Touchpad
Operating system installed	Ubuntu Linux
Processor code	SR170
Processor ARK ID	75459
Intel TSX-NI version	0.00
Processor package size	40 x 24 x 1.5 mm
Intel ME Firmware Version	9.5
Supported instruction sets	AVX 2.0
Intel Smart Connect Technology version	1.00
Battery life (max)	- h
AC adapter power	65 W

Weight and Dimensions

Depth	258 mm
Width	385.6 mm
Height	22.6 mm
Weight	2330 g
