HP Pavilion 15 User Manual

Component Spare part number
For use in Switzerland 755530-111
For use in Japan 755530-291
For use in Israel 755530-BB1
For use in South Aftrica 755530-AR1
Screw Kit for HP Pavilion 15 Notebook PC 762522-001
Screw Kit for HP Pavilion 17 Notebook PC 765790-001
HDMI to VGA Adapter for use with computer models with AMD processors 701943-001
Rubber kit for HP Pavilion 15 Notebook PC 763104-001
Rubber kit for HP Pavilion 17 Notebook PC 763714-001
Notebook sleeve for HP Pavilion 15 Notebook PC 777944-001
Case sleeve for HP Pavilion 15 Notebook PC 776506-001
Heat spreader for use with Intel computer models 784982-001
Sequential part number listing
Spare part
number
Description Regulatory Model Number
TPN-
Q140
TPN-
Q143
TPN-
Q144
TPN-
Q141
652972-005 2 GB memory module for HP Pavilion 15 Notebook PC √ √
670034-005 8 GB memory module for HP Pavilion 17 Notebook PC √ √
691739-005 2 GB memory module for HP Pavilion 17 Notebook PC √ √
691740-005 4 GB memory module √ √ √ √
693374-001 8 GB memory module for HP Pavilion 15 Notebook PC √
697917-001 RTC battery √ √ √ √
701943-001 HDMI to VGA adapter for use with computer models with AMD
processors
√√√
709848-005 Realtek RTL8188EE 802.11 bgn Wi-Fi Adapter available for
Windows 8.1 and Windows 7
√√√√
710412-001 65 W HP Smart AC adapter (nPFC, RC, 3-wire, 4.5 mm), select
models only
√√√√
710413-001 90 W HP Smart AC adapter (PFC, RC, 3-wire, 4.5 mm) for use
with computer models with AMD processors select models only
√√
710414–001 90 W HP Smart AC adapter Slim (PFC, RC, 3-wire, 4.5 mm) for
use with computer models with AMD processors select models
only
√
710662-005 WLAN Intel Dual Band Wireless-AC 3160 802.11 ac 1x1 WiFi +
BT 4.0 combo adapter, for use only on computer models
equipped with Intel processors
√ √
Sequential part number listing 45

HP Pavilion 15 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Country of origin	China
Bus type	DMI2
Stepping	C0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-4200U
System bus rate	- GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4200 Mobile series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Haswell
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.6 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x4, 2x4
Thermal Design Power (TDP)	15 W
Maximum number of PCI Express lanes	12
Accelerometer	Yes
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 4 GB
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
HD type	Not supported
Display surface	Gloss
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0xA16
Discrete graphics card model	AMD Radeon HD 8670M
On-board graphics card model	Intel® HD Graphics 4400
Discrete graphics memory type	GDDR3
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	200 MHz
On-board graphics card dynamic frequency (max)	1000 MHz
Audio system	DTS Sound+
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Pointing device	Touchpad
Operating system installed	Ubuntu Linux
Processor code	SR170
Processor ARK ID	75459
Intel TSX-NI version	0.00
Processor package size	40 x 24 x 1.5 mm
Intel ME Firmware Version	9.5
Supported instruction sets	AVX 2.0
Intel Smart Connect Technology version	1.00
Battery life (max)	- h
AC adapter power	65 W

Weight and Dimensions

Depth	258 mm
Width	385.6 mm
Height	22.6 mm
Weight	2330 g
