HP Pavilion 15 User Manual

Spare part
number
Description Regulatory Model Number
TPN-
Q140
TPN-
Q143
TPN-
Q144
TPN-
Q141
714657-001 65 W HP Smart AC adapter (nPFC, RC, 3-wire, 4.5 mm), select
models only
√
724935-005 WLAN Broadcom BCM 4352 WLAN 802.11 AC+BT4 2x2HMC
for HP Pavilion 15 AMD computer models available for Windows
8.1 and Windows 7
√
731999-005 Hard drive 1 TB, 5400 rpm + 8 GB NAND hybrid, 9.5 mm √√√√
732000-005 Hard drive 500 GB 5400 rpm + 8 GB NAND hybrid, 7 mm √ √ √√
732001-005 Hard drive, 750 GB 5400 rpm + 8 GB NAND hybrid, 9.5 mm√ √ √√
741727-001 45 W HP Smart AC adapter (nPFC, RC, 3-wire, 4.5 mm), nslim √ √ √ √
747375-005 Hard drive 1.5 TB 5400-RPM SATA RAW 9.5 mm √
753076-005 WLAN Broadcom BCM43142 802.11 bgn 1x1 Wi-Fi + BT4.0
HMC combo adapter for use only with HP Pavilion 17 Notebook
PC computer modelss or HP Pavilion 15 Notebook PC computer
models
√ √
753077-005 WLAN Realtek RT8723BE 802.11 bgn 1x1 Wi-Fi + BT4.0 combo
adapter, for use only on computer models equipped with AMD
processors available for Windows 8.1 and Windows 7
√√
755530-001 Power cord for use in North America (3 pin, black, 1.0 m) √ √ √ √
755530-011 Power cord for use in Australia (3 pin, black, 1.0 m), for use with
computer models with Intel processors
√√
755530-021 Power cord for use in Europe (3 pin, black, 1.0 m), for use with
computer models with Intel processors
√√√√
755530-031 Power cord for use in the United Kingdom and Singapore (3 pin,
black, 1.0 m), for use with computer models with Intel processors
√√√√
755530-061 Power cord for use in Italy (3 pin, black, 1.0 m) √
755530-081 Power cord for use in Denmark (3 pin, black, 1.0 m) √ √√√
755530-111 Power cord for use in Switzerland (3 pin, black, 1.0 m) √ √ √ √
755530-201 Power cord for use in Thailand (3 pin, black, 1.0 m), for use with
computer models with Intel processors
√
755530-291 Power cord for use in Japan (3 pin, black, 1.0 m), for use in
Japan
√
755530-AA1 Power cord for use in People’s Republic of China (3 pin, black,
1.0 m), for use with computer models with Intel processors
√
755530-AB1 Power cord for use in Taiwan (3 pin, black, 1.0 m), for use with
computer models with Intel processors
√
755530-AD1 Power cord for use in South Korea (3 pin, black, 1.0 m), for use
with computer models with Intel processors
√
755530-AR1 Power cord for use in South Africa (3 pin, black, 1.0 m) √ √
755530-BB1 Power cord for use in Israel (3 pin, black, 1.0 m) √ √ √
46 Chapter 3 Illustrated parts catalog

HP Pavilion 15 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Country of origin	China
Bus type	DMI2
Stepping	C0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-4200U
System bus rate	- GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4200 Mobile series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Haswell
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.6 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x4, 2x4
Thermal Design Power (TDP)	15 W
Maximum number of PCI Express lanes	12
Accelerometer	Yes
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 4 GB
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
HD type	Not supported
Display surface	Gloss
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0xA16
Discrete graphics card model	AMD Radeon HD 8670M
On-board graphics card model	Intel® HD Graphics 4400
Discrete graphics memory type	GDDR3
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	200 MHz
On-board graphics card dynamic frequency (max)	1000 MHz
Audio system	DTS Sound+
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Pointing device	Touchpad
Operating system installed	Ubuntu Linux
Processor code	SR170
Processor ARK ID	75459
Intel TSX-NI version	0.00
Processor package size	40 x 24 x 1.5 mm
Intel ME Firmware Version	9.5
Supported instruction sets	AVX 2.0
Intel Smart Connect Technology version	1.00
Battery life (max)	- h
AC adapter power	65 W

Weight and Dimensions

Depth	258 mm
Width	385.6 mm
Height	22.6 mm
Weight	2330 g
