HP Pavilion 15 User Manual

Category Description AMD Intel
●
Realtek RT8723BE 802.11 bgn 1x1 Wi-Fi + BT4.0 combo adapter
(with single antenna) available for Windows 8.1 and Windows 7
●
Broadcom BCM 4352 802.11 ac 2x2 WiFi + BT 4.0 Combo Adapter
(with dual antenna ) available for Windows 8.1 and Windows 7
●
Realtek RTL8188EE 802.11 bgn 1x1 Wi-Fi adapter (with single
antenna) available for Windows 8.1 and Windows 7
●
Broadcom BCM43142 802.11 bgn 1x1 Wi-Fi + BT4.0 HMC combo
adapter (with single antenna) available for Windows 8.1 and
Windows 7
●
Intel Dual Band Wireless-AC 3160 802.11 ac 1x1 WiFi + BT 4.0
combo adapter (with dual antennas)
√
External media
cards
HP Multi-Format Memory Card Reader slot with push-push technology,
supporting the following digital card formats:
Supports memory cards such as Secure Digital SD/SDHC/SDXC
√√
Ports
●
AC Smart Pin adapter plug (4.5 mm barrel)
●
Combination audio-out (stereo headphone)/audio-in (mono
microphone)
●
RJ-45 (Ethernet)
●
USB 3.0 (2 ports), USB 2.0 (1 port)
√√
●
HDMI version 1.4 output supporting 1920 x 1080 @ 60 Hz Hot Plug /
Unplug and auto detect for correct output to wide-aspect versus
standard aspect video
√√
Keyboard/
pointing
devices
Full Size Textured island-style Keyboard with numeric key pad black
Full Size Textured island-style Keyboard with numeric key pad white
Clickpad with image sensor
Multitouch gestures enabled
Supports Windows
®
8 Modern Trackpad Gestures
√√
Full Size Backlit 3 Coat paint island-style Keyboard with numeric keypad
black with red LED for AMD HP Pavilion 15 PC models Beats Audio
Special Edition
√
Power
requirements
Supports the following AC adapters:
●
45 W HP Smart AC adapter (nPFC, 3-wire, 4.5 mm, nslim)
√√
●
65 W HP Smart AC adapter (nPFC, 3-wire, 4.5 mm)
●
65 W HP Smart AC adapter (nPFC, 3-wire, 4.5 mm, nslim
√√
●
90 W Smart AC adapter (PFC, 3-wire, 4.5 mm)
●
90 W AC adapter (PFC, 3-wire, 4.5 mm)
√
Supports battery fast charge
Supports the following batteries (battery is user-removable)
●
4 cell battery - 41 Whr (2.8 AH)
√√
Security
●
Security cable lock √ √
5

HP Pavilion 15 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Country of origin	China
Bus type	DMI2
Stepping	C0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-4200U
System bus rate	- GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4200 Mobile series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Haswell
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.6 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x4, 2x4
Thermal Design Power (TDP)	15 W
Maximum number of PCI Express lanes	12
Accelerometer	Yes
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 4 GB
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
HD type	Not supported
Display surface	Gloss
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0xA16
Discrete graphics card model	AMD Radeon HD 8670M
On-board graphics card model	Intel® HD Graphics 4400
Discrete graphics memory type	GDDR3
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	200 MHz
On-board graphics card dynamic frequency (max)	1000 MHz
Audio system	DTS Sound+
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Pointing device	Touchpad
Operating system installed	Ubuntu Linux
Processor code	SR170
Processor ARK ID	75459
Intel TSX-NI version	0.00
Processor package size	40 x 24 x 1.5 mm
Intel ME Firmware Version	9.5
Supported instruction sets	AVX 2.0
Intel Smart Connect Technology version	1.00
Battery life (max)	- h
AC adapter power	65 W

Weight and Dimensions

Depth	258 mm
Width	385.6 mm
Height	22.6 mm
Weight	2330 g
