HP Pavilion 15 User Manual

Item Component Spare part
number
AMD A8-5545M W8STD for use with Windows Standard HP
Pavilion 15 Notebook PC
766713-501
For computer models equipped with AMD processors and
Discrete graphics
AMD M260 A6-6310 (2.4 GHz/1.8 GHz, 2 MB L2, 1600 MHz
DDR3L, quad core, 15 W) for use with FreeDOS and Ubuntu
Linux HP Pavilion 17 Notebook PC
763425-001
AMD M260 A6-6310 (2.4 GHz/1.8 GHz, 2 MB L2, 1600 MHz
DDR3L, quad core, 15 W) for use with Windows Standard HP
Pavilion 17 Notebook PC
763425-501
AMD M260 A6-6310 (2.4 GHz/1.8 GHz, 2 MB L2, 1600 MHz
DDR3L, quad core, 15 W) for use with FreeDOS and Ubuntu
Linux HP Pavilion 15 Notebook PC
762532-001
AMD M260 A6-6310 (2.4 GHz/1.8 GHz, 2 MB L2, 1600 MHz
DDR3L, quad core, 15 W) for use with Windows Standard HP
Pavilion 15 Notebook PC
762532-501
AMD M260 A6-6310 (2.4 GHz/1.8 GHz, 2 MB L2, 1600 MHz
DDR3L, quad core, 15 W) for use with Windows Professional
HP Pavilion 15 Notebook PC
762532-601
AMD A8-6410 (2.4 GHz/2.0 GHz, 2 MB L2, 1600 MHz DDR3L,
quad core, 15 W) for use with FreeDOS and Ubuntu Linux HP
Pavilion 17 Notebook PC
763427-001
AMD A8-6410 (2.4 GHz/2.0 GHz, 2 MB L2, 1600 MHz DDR3L,
quad core, 15 W) for use with Windows Standard HP Pavilion
17 Notebook PC
763427-501
AMD M260 A8-6410 (2.4 GHz/2.0 GHz, 2 MB L2, 1600 MHz
DDR3L, quad core, 15 W) for use with FreeDOS and Ubuntu
Linux HP Pavilion 15 Notebook PC
762531-001
AMD M260 A8-6410 (2.4 GHz/2.0 GHz, 2 MB L2, 1600 MHz
DDR3L, quad core, 15 W) for use with Windows Standard HP
Pavilion 15 Notebook PC
762531-501
AMD M260 A8-6410 (2.4 GHz/2.0 GHz, 2 MB L2, 1600 MHz
DDR3L, quad core, 15 W) for use with Windows Professional
HP Pavilion 15 Notebook PC
762531-601
AMD M260 A10-5745M (2.9 GHz/2.1 GHz, 4 MB L2, 1333
MHz DDR3L, quad core, 25 W) for use with FreeDOS and
Ubuntu Linux HP Pavilion 17 Notebook PC
763428-001
AMD M260 A10-5745M (2.9 GHz/2.1 GHz, 4 MB L2, 1333
MHz DDR3L, quad core, 25 W) for use with Windows
Standard HP Pavilion 17 Notebook PC
763428-501
AMD M260 A10-5745M (2.9 GHz/2.1 GHz, 4 MB L2, 1333
MHz DDR3L, quad core, 25 W) for use with FreeDOS and
Ubuntu Linux HP Pavilion 15 Notebook PC
766715-001
AMD M260 A10-5745M (2.9 GHz/2.1 GHz, 4 MB L2, 1333
MHz DDR3L, quad core, 25 W) for use with Windows
Standard HP Pavilion 15 Notebook PC
766715-501
36 Chapter 3 Illustrated parts catalog

HP Pavilion 15 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Country of origin	China
Bus type	DMI2
Stepping	C0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-4200U
System bus rate	- GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4200 Mobile series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Haswell
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.6 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x4, 2x4
Thermal Design Power (TDP)	15 W
Maximum number of PCI Express lanes	12
Accelerometer	Yes
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 4 GB
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
HD type	Not supported
Display surface	Gloss
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0xA16
Discrete graphics card model	AMD Radeon HD 8670M
On-board graphics card model	Intel® HD Graphics 4400
Discrete graphics memory type	GDDR3
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	200 MHz
On-board graphics card dynamic frequency (max)	1000 MHz
Audio system	DTS Sound+
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Pointing device	Touchpad
Operating system installed	Ubuntu Linux
Processor code	SR170
Processor ARK ID	75459
Intel TSX-NI version	0.00
Processor package size	40 x 24 x 1.5 mm
Intel ME Firmware Version	9.5
Supported instruction sets	AVX 2.0
Intel Smart Connect Technology version	1.00
Battery life (max)	- h
AC adapter power	65 W

Weight and Dimensions

Depth	258 mm
Width	385.6 mm
Height	22.6 mm
Weight	2330 g
