Spare part
number
Description Regulatory Model Number
TPN-
Q140
TPN-
Q143
TPN-
Q144
TPN-
Q141
762513-001 15.6 LED BrightView HD SVA HD, WLED, SVA flat display panel
(includes screws) available for Windows 8.1 and Windows 7
√√
762514-001 Display back cover (includes screws): natural silver finish,
Touchscreen for HP Pavilion 15 Notebook PC
√√
762515-001 Display back cover (includes screws):snow white, Touchscreen
for HP Pavilion 15 Notebook PC
√√
762516-001 Display back cover (includes screws): vibrant red finish,
Touchscreen for HP Pavilion 15 Notebook PC
√√
762517-001 Display back cover (includes screws): aqua blue finish,
Touchscreen for HP Pavilion 15 Notebook PC
√√
762518-001 WLAN Antenna Kit for use with HP Pavilion 15 Notebook PC
computer non-touch models (includes left and right wireless
antenna cables and transceivers)
√√
762519-001 Display panel cable HD cable for non-Touchscreen models for
HP Pavilion 15 Notebook PC computer models:
√√
762520-001 Display Hinge Kit, non-touchscreen (includes left and right
hinges and screws) for HP Pavilion 15 Notebook PC
√√
762521-001 Webcamera/microphone module (includes adhesive and screws)
for HP Pavilion 15 Notebook PC
√√
762522-001 Screw Kit for HP Pavilion 15 Notebook PC √ √
762524-001 Heat sink for use only on computer models equipped with a
graphics subsystem with AMD switchable discrete graphics, 19
W for use with HP Pavilion 15 Notebook PC computer models
√
762525-001 TouchPad board (with bracket and cable) In Ash Silver for use
with HP Pavilion 15 Notebook PC computer models
√
762526-001 System board AMD A8-6410 (2.4 GHz/2.0 GHz, 2 MB L2, 1600
MHz DDR3L, quad core, 15 W) for use with FreeDOS and
Ubuntu Linux HP Pavilion 15 Notebook PC
√
762526-501 System board AMD A8-6410 (2.4 GHz/2.0 GHz, 2 MB L2, 1600
MHz DDR3L, quad core, 15 W) for use with Windows Standard
HP Pavilion 15 Notebook PC
√
762526-601 System board AMD A8-6410 (2.4 GHz/2.0 GHz, 2 MB L2, 1600
MHz DDR3L, quad core, 15 W) for use with Windows
Professional HP Pavilion 15 Notebook PC
√
762527-001 System board AMD A8-6410 (2.4 GHz/2.0 GHz, 2 MB L2, 1600
MHz DDR3L, quad core, 15 W) for use with FreeDOS and
Ubuntu Linux HP Pavilion 17 Notebook PC
√
762527-501 System board AMD A8-6410 (2.4 GHz/2.0 GHz, 2 MB L2, 1600
MHz DDR3L, quad core, 15 W) for use with Windows Standard
HP Pavilion 17 Notebook PC
√
762527-601 System board AMD M260 A8-6410 (2.4 GHz/2.0 GHz, 2 MB L2,
1600 MHz DDR3L, quad core, 15 W) for use with FreeDOS and
Ubuntu Linux HP Pavilion 15 Notebook PC
√
48 Chapter 3 Illustrated parts catalog

HP Pavilion 15 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Country of origin	China
Bus type	DMI2
Stepping	C0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-4200U
System bus rate	- GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4200 Mobile series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Haswell
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.6 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x4, 2x4
Thermal Design Power (TDP)	15 W
Maximum number of PCI Express lanes	12
Accelerometer	Yes
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 4 GB
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
HD type	Not supported
Display surface	Gloss
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0xA16
Discrete graphics card model	AMD Radeon HD 8670M
On-board graphics card model	Intel® HD Graphics 4400
Discrete graphics memory type	GDDR3
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	200 MHz
On-board graphics card dynamic frequency (max)	1000 MHz
Audio system	DTS Sound+
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Pointing device	Touchpad
Operating system installed	Ubuntu Linux
Processor code	SR170
Processor ARK ID	75459
Intel TSX-NI version	0.00
Processor package size	40 x 24 x 1.5 mm
Intel ME Firmware Version	9.5
Supported instruction sets	AVX 2.0
Intel Smart Connect Technology version	1.00
Battery life (max)	- h
AC adapter power	65 W

Weight and Dimensions

Depth	258 mm
Width	385.6 mm
Height	22.6 mm
Weight	2330 g
