Page #77 background imageLoading...
Page #77 background image
Spare part
number
Description Regulatory Model Number
TPN-
Q140
TPN-
Q143
TPN-
Q144
TPN-
Q141
778947-501 Intel Core 840M i7-4500U (1.8 GHz, SC turbo up to 3.0 GHz),
1600 MHz/2 MB L3, Dual 1 5W for use with Windows Standard
HP Pavilion 17 Notebook PC
778948-001 Intel Core 840M i5-4200U (1.6 GHz, SC turbo up to 2.6 GHz),
1600 MHz/2 MB L3, Dual 15 W for use with FreeDOS and
Ubuntu Linux HP Pavilion 17 Notebook PC
778948-501 Intel Core 840M i5-4200U (1.6 GHz, SC turbo up to 2.6 GHz),
1600 MHz/2 MB L3, Dual 15 W for use with Windows Standard
HP Pavilion 17 Notebook PC
778949-001 Intel Core 830M i5-4200U (1.6 GHz, SC turbo up to 2.6 GHz),
1600 MHz/2 MB L3, Dual 15 W for use with FreeDOS and
Ubuntu Linux HP Pavilion 17 Notebook PC
778949-501 Intel Core 830M i5-4200U (1.6 GHz, SC turbo up to 2.6 GHz),
1600 MHz/2 MB L3, Dual 15 W for use with Windows Standard
HP Pavilion 17 Notebook PC
779127-001 System board Intel Core i3-4005U (1.7GHz), 1600 MHz/3 MB
L3, dual 15 W for use with FreeDOS and Ubuntu Linux for use
with HP Pavilion 17 Notebook PC
779127-501 System board Intel Core i3-4005U (1.7 GHz), 1600 MHz/3 MB
L3, dual 15 W for use with FreeDOS and Ubuntu Linux for use
with Windows Standard HP Pavilion 17 Notebook PC available
for Windows 8.1 and Windows 7
779639-001 Back cover neon purple for use with Windows Standard HP
Pavilion 15 Notebook PC
√√
779839-001 System board Intel Core i3-4005U (1.7 GHz), 1600 MHz/3 MB
L3, dual 15 W for use with FreeDOS and Ubuntu Linux HP
Pavilion 15 Notebook PC
779839-501 System board Intel Core i3-4005U (1.7 GHz), 1600 MHz/3 MB
L3, dual 15 W for use with Windows Standard HP Pavilion 15
Notebook PC available for Windows 8.1 and Windows 7
779839-601 System board Intel Core i3-4005U (1.7 GHz), 1600 MHz/3 MB
L3, dual 15 W for use with Windows Professional HP Pavilion 15
Notebook PC available for Windows 8.1 and Windows 7
779840-001 System board Intel Core 830 M i3-4005U (1.7 GHz), 1600MHz/2
MB L3, Dual 15 W
779840-501 System board Intel Core 830 M i3-4005U (1.7 GHz), 1600 MHz/2
MB L3, dual 15 W for use with Windows Standard HP Pavilion
15 Notebook PC available for Windows 8.1 and Windows 7
779840-601 System board Intel Core 830 M i3-4005U (1.7 GHz), 1600 MHz/2
MB L3, dual 15 W for use with Windows Professional HP
Pavilion 15 Notebook PC available for Windows 8.1 and
Windows 7
780084-001 Base enclosure snow white for use with AMD processors for use
with HP Pavilion 7 Notebook PC
780085-001 Base enclosure aqua blue for use with AMD processors for use
with HP Pavilion 17 Notebook PC
Sequential part number listing 67

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Pavilion 15 and is the answer not in the manual?

HP Pavilion 15 Specifications

General IconGeneral
Form factorClamshell
Product typeLaptop
Product colorBlack
Country of originChina
Bus typeDMI2
SteppingC0
Tjunction100 °C
Processor cache3 MB
Processor cores2
Processor modeli5-4200U
System bus rate- GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-4200 Mobile series
Processor socketBGA 1168
Processor threads4
Processor codenameHaswell
Processor frequency1.6 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency2.6 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x4, 2x4
Thermal Design Power (TDP)15 W
Maximum number of PCI Express lanes12
AccelerometerYes
Motherboard chipset-
Memory slots2x SO-DIMM
Internal memory4 GB
Memory clock speed1600 MHz
Internal memory typeDDR3L-SDRAM
Maximum internal memory- GB
Memory layout (slots x size)1 x 4 GB
HDD speed5400 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Total storage capacity500 GB
Compatible memory cardsSD
Number of HDDs installed1
HD typeNot supported
Display surfaceGloss
Display diagonal15.6 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
On-board graphics card ID0xA16
Discrete graphics card modelAMD Radeon HD 8670M
On-board graphics card modelIntel® HD Graphics 4400
Discrete graphics memory typeGDDR3
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory1.74 GB
On-board graphics card base frequency200 MHz
On-board graphics card dynamic frequency (max)1000 MHz
Audio systemDTS Sound+
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates10, 100 Mbit/s
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity0
Pointing deviceTouchpad
Operating system installedUbuntu Linux
Processor codeSR170
Processor ARK ID75459
Intel TSX-NI version0.00
Processor package size40 x 24 x 1.5 mm
Intel ME Firmware Version9.5
Supported instruction setsAVX 2.0
Intel Smart Connect Technology version1.00
Battery life (max)- h
AC adapter power65 W
Weight and Dimensions IconWeight and Dimensions
Depth258 mm
Width385.6 mm
Height22.6 mm
Weight2330 g
