3. Remove five screws (1) around the battery area, three broadhead screws (2) in the optical drive
bay and one screw (3) near the display hinge.
NOTE: Some models may have two screws in the optical drive bay (2).
4. Turn the computer right side up and carefully remove the top cover.
NOTE: Use a thin, non-conductive tool to lift the top cover..
5. Carefully disconnect the following cables:
●
Power button cable (1)
●
Keyboard cable (2)
●
TouchPad cable (3)
Lift the top cover (4) to remove it from the computer.
86 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
