Table 3-1 Computer major components and their descriptions
Item Component Spare part number
(1) Display assembly: The display assembly is spared at the subcomponent level only. For more display assembly spare part
information, see Display assembly components on page 23.
(2) Top cover with keyboard:
Natural silver, backlit L24752-xx1
Natural silver, no backlight L24753-xx1
Pale gold, backlit L24754-xx1
Pale gold, no backlight L24755-xx1
Cloud blue, backlight L49391-xx1
Cloud blue, no backlight L49392-xx1
Luminous gold, backlight L49393-xx1
Luminous gold, no backlight L49394-xx1
Top cover with keyboard (on models equipped with GTX graphics):
Natural silver, backlit L35339–xx1
Natural silver, no backlight L35340–xx1
(3) Power connector cable:
Power connector cable EMI tape is available in the Miscellaneous Parts Kit using spare part
number L28015-001.
810327-006
Power connector cable in models equipped with GTX graphics L45827-001
(4) TouchPad:
NOTE: The TouchPad cable is available using spare part number L23893-001.
Natural silver L24934-001
Pale gold L24933-001
Fog blue L51805-001
Warm gold L51806-001
(5) TouchPad bracket L23892-001
(6) Speakers (includes cable) L23900-001
Speakers (on models equipped with GTX graphics) (include cable) L41588-001
(7) System board (includes processor and replacement thermal material):
System board for use in models with discrete graphics equipped with the following processors:
Intel Core i7-8565U processor and 4 GB of MX 250 discrete video memory L50260-xx1
Intel Core i7-8565U processor and 2 GB of MX 250 discrete video memory L50259-xx1
Intel Core i7-8565U processor and 4 GB of GTX 1050 discrete video memory L34171-xx1
Intel Core i7-8565U processor and 4 GB of GeForce MX150 discrete video memory L34176-xx1
Intel Core i7-8565U processor and 2 GB of GeForce MX150 discrete video memory L34175-xx1
Computer components 19
