d. Remove the display bezel (4) from the display assembly.
The display bezel is available using spare part number 933464-001.
10. If it is necessary to replace the webcam/microphone module:
NOTE: The webcam/microphone module can be removed and replaced without removing the display
assembly from the keyboard/top cover.
a. Remove the display bezel.
b. Disconnect the display panel cable (1) from the webcam/microphone module.
48 Chapter 5 Removal and replacement procedures
