9, Disassemble Webcam
Remove the cable and screw in order to disengage the webcam module and mechanical parts.
10, Disassemble Wireless card
Remove one or two cables and 1pcs screw in order to remove wireless card.
11, Disassemble the cables connected to MB and Base pan.
