5–32 Maintenance and Service Guide
Removal and Replacement Procedures
Display Assembly Subcomponents
Spare Part Number Information
Display Plastics Kit, includes:
■ Display bezel
■ Display enclosure
■ Display release latch actuator and hooks
407792-001
Display Hinge Kit 407796-001
Display inverter board 407800-001
Display Panel Kit (includes display panel cable)
■ 15.4-inch, WXGA with BrightView
■ 15.4-inch, WXGA antiglare
407799-001
407798-001
Wireless Antenna Kit (includes cable and transceivers) 407791-001
Display Label Kit (not illustrated) 407864-001
Display Screw Kit (not illustrated), includes:
■ Phillips PM2.5×7.0 screws
■ Phillips PM2.0×4.0 screws
■ Rubber screw covers
407794-001
