HP Pavilion DV5000 Maintenance And Service Guide

Removal and Replacement Procedures
Maintenance and Service Guide 5–31
Ä
CAUTION: Support the display assembly when removing the following
screws. Failure to support the display assembly can result in damage to
the display assembly and other computer components.
9. Remove the four Phillips PM2.5×7.0 screws 1 that secure
the display assembly to the computer.
10. Lift the display assembly straight up and remove it 2.
Removing the Display Assembly
Download from Www.Somanuals.com. All Manuals Search And Download.

HP Pavilion DV5000 Specifications

General

CPU	Intel Pentium M or Intel Celeron M
Chipset	Intel 915GM
Memory	Up to 2 GB DDR2
Graphics	Intel Graphics Media Accelerator 900
Display	15.4-inch WXGA
Hard Drive	40 GB to 100 GB
Optical Drive	DVD\u00b1RW
Wireless	802.11b/g
Operating System	Windows XP Home or Windows XP Professional
Battery Life	Up to 3 hours
Ports	3 USB 2.0, VGA, S-Video, Ethernet, Modem, Headphone, Microphone, ExpressCard/54
