5–36 Maintenance and Service Guide
Removal and Replacement Procedures
15. Remove the two Phillips PM2.5×7.0 screws 1 that secure
the display panel to the display enclosure.
16. Remove the display panel 2 and inverter board 3.
Removing the Display Panel and Inverter Board
Display Assembly Subcomponents
Spare Part Number Information
Display Panel Kit (includes display panel cable)
■ 15.4-inch, WXGA with BrightView
■ 15.4-inch, WXGA antiglare
407799-001
407798-001
Display inverter board 407800-001
