HP Pavilion DV5000 - Page 138

5–54 Maintenance and Service Guide
Removal and Replacement Procedures
10. Remove the two Phillips PM2.5×11.0 screws 1 and the three
Phillips PM2.5×6.0 screws 2 that secure the system board
to the base enclosure.
11. Remove the ExpressCard bracket 3.
✎
The ExpressCard bracket is included in the Bracket Kit, spare
part number 407820-001.
Removing the System Board Screws
