5ā56 Maintenance and Service Guide
Removal and Replacement Procedures
14. If it is necessary to replace the power connector cable, turn
the system board upside down with the expansion port 2
docking connector toward you.
15. Disconnect the power connector cable 1 from the system
board.
16. Remove the power connector cable 2.
ā
The power connector cable is available in the Cable Kit, spare
part number 407774-001.
Removing the Power Connector Cable
