5–8 Maintenance and Service Guide
Removal and Replacement Procedures
4. Remove the two Phillips PM2.5×6.0 hard drive retention
screws 1 that secure the hard drive to the computer.
5. Slide the hard drive 2 to the right to disconnect if from
the system board.
6. Remove the hard drive 3 from the hard drive bay.
Removing the Hard Drive
