Maintenance and Service Guide 7–1
7
Screw listing
This section provides specification and reference information for the screws used in the computer. The screws
listed in this section are available in the Screw Kit, spare part number 496890-001.
Phillips PM2.5×7.0 screw
Where used:
1 One screw that secures the optical drive to the computer
2 Two screws that secure the switch cover to the computer
3 Two screws that secure the keyboard to the computer
Color Quantity Length Thread Head diameter
Black 39 7.0 mm 2.5 mm 5.0 mm
