HP PAVILION DV8

7–16 Maintenance and Service Guide
Screw listing
Phillips PM2.0×11.0 captive screw
Where used: 4 captive screws that secure the fan/heat sink assembly to the system board (screws are secured by
Orings)
Color Quantity Length Thread Head diameter
Silver 4 11.0 mm 2.0 mm 5.0 mm
