Illustrated parts catalog
Maintenance and Service Guide 3–11
496876-001 Display Cable Kit (includes wireless antenna transceivers and cables, webcam/microphone module
cable, and display panel cable)
496887-001 Speaker assembly
496889-001 Rubber Feet Kit (includes 7 rubber feet)
496890-001 Screw Kit
496891-001 Cable Kit (includes TV tuner module cable)
498324-001 Display inverter
499242-001 Webcam/microphone module
501911-001 500-GB, 5400-rpm hard drive (includes left and right brackets, Mylar sleeve, connector, and isolators)
503484-001 250-GB, 5400-rpm hard drive (includes left and right brackets, Mylar sleeve, connector, and isolators)
503485-001 320-GB, 5400-rpm hard drive (includes left and right brackets, Mylar sleeve, connector, and isolators)
503487-001 Blu-ray ROM DVD±RW SuperMulti DL Drive (includes optical drive bezel and bracket)
503488-001 Blu-ray ROM with LightScribe DVD±RW SuperMulti DL Drive (includes optical drive bezel
and bracket)
507552-001 250-GB, 7200-rpm hard drive (includes left and right brackets, Mylar sleeve, connector, and isolators)
507553-001 320-GB, 7200-rpm hard drive (includes left and right brackets, Mylar sleeve, connector, and isolators)
514290-001 Fan
516916-001 4-cell, 63-Wh Li-ion battery
537921-001 Bluetooth module cable
572507-001 Intel WiFi Link 5100 802.11 a/g/n WLAN module for use in Andorra, Antigua and Barbuda,
Argentina, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Barbados, Belgium,
Bermuda, Bolivia, Bosnia, Brazil, Brunei, Bulgaria, Canada, the Cayman Islands, Chile, Colombia,
Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, the Dominican Republic, Ecuador, Egypt,
El Salvador, Estonia, Finland, France, French Guiana, Georgia, Germany, Ghana, Greece,
Guadeloupe, Guam, Guatemala, Haiti, Herzegovina, Honduras, Hong Kong, Hungary, Iceland, India,
Indonesia, Ireland, Israel, Italy, the Ivory Coast, Jamaica, Japan, Jordan, Kenya, Kuwait, Kyrgyzstan,
Latvia, Lebanon, Liechtenstein, Lithuania, Luxembourg, Malawi, Malaysia, Malta, Martinique,
Mauritius, Mexico, Monaco, Montenegro, Morocco, the Nether Antilles, the Netherlands,
New Zealand, Nicaragua, Nigeria, Norway, Oman, Pakistan, Panama, Paraguay,
the People's Republic of China, Peru, the Philippines, Poland, Portugal, Puerto Rico, Qatar, Romania,
San Marino, Saudi Arabia, Senegal, Singapore, Slovakia, Slovenia, South Africa, South Korea, Spain,
Sri Lanka, Sweden, Switzerland, Taiwan, Tanzania, Thailand, Trinidad and Tobago, Turkey,
the United Arab Emirates, the United Kingdom, the United States, Uruguay, the U.S. Virgin Islands,
Venezuela, and Vietnam
572508-001 Intel WiFi Link 5100 802.11 a/b/g WLAN module for use in Andorra, Antigua and Barbuda,
Argentina, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Barbados, Belgium,
Bermuda, Bolivia, Bosnia, Brazil, Brunei, Bulgaria, Canada, the Cayman Islands, Chile, Colombia,
Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, the Dominican Republic, Ecuador, Egypt,
El Salvador, Estonia, Finland, France, French Guiana, Georgia, Germany, Ghana, Greece,
Guadeloupe, Guam, Guatemala, Haiti, Herzegovina, Honduras, Hong Kong, Hungary, Iceland, India,
Indonesia, Ireland, Israel, Italy, the Ivory Coast, Jamaica, Japan, Jordan, Kenya, Kuwait, Kyrgyzstan,
Latvia, Lebanon, Liechtenstein, Lithuania, Luxembourg, Malawi, Malaysia, Malta, Martinique,
Mauritius, Mexico, Monaco, Montenegro, Morocco, the Nether Antilles, the Netherlands,
New Zealand, Nicaragua, Nigeria, Norway, Oman, Pakistan, Panama, Paraguay,
the People's Republic of China, Peru, the Philippines, Poland, Portugal, Puerto Rico, Qatar, Romania,
San Marino, Saudi Arabia, Senegal, Singapore, Slovakia, Slovenia, South Africa, South Korea, Spain,
Sri Lanka, Sweden, Switzerland, Taiwan, Tanzania, Thailand, Trinidad and Tobago, Turkey,
the United Arab Emirates, the United Kingdom, the United States, Uruguay, the U.S. Virgin Islands,
Venezuela, and Vietnam
(Continued)
