libraries, desktop, contacts, and favorites. If files are accidentally deleted from the hard drive and
they can no longer be restored from the Recycle Bin, or if files become corrupted, you can restore
the files that you backed up using File History. Restoring files is also useful if you ever choose to
reset the computer by reinstalling Windows or choose to recover using HP Recovery Manager.
NOTE: File History is not enabled by default, so you must turn it on.
For more information and steps for enabling Windows File History, see Help and Support. From
the Start screen, type h, and then select Help and Support.
Creating HP Recovery media
HP Recovery Manager is a software program that offers a way to create recovery media after you
successfully set up the computer. HP Recovery media can be used to perform system recovery if the
hard drive becomes corrupted. System recovery reinstalls the original operating system and the
software programs installed at the factory, and then configures the settings for the programs. HP
Recovery media can also be used to customize the system or aid in the replacement of a hard drive.
Only one set of HP Recovery media can be created. Handle these recovery tools carefully, and
keep them in a safe place.
HP Recovery Manager examines the computer and determines the required storage capacity for
the blank USB flash drive or the number of blank DVD discs that will be required.
To create recovery discs, your computer must have an optical drive with DVD writer capability,
and you must use only high-quality blank DVD-R, DVD+R, DVD-R DL, or DVD+R DL discs. Do not
use rewritable discs such as CD±RW, DVD±RW, double-layer DVD±RW, or BD-RE (rewritable Blu-
ray) discs; they are not compatible with HP Recovery Manager software. Or instead you can use a
high-quality blank USB flash drive.
If your computer does not include an integrated optical drive with DVD writer capability, but you
would like to create DVD recovery media, you can use an external optical drive (purchased
separately) to create recovery discs, or you can obtain recovery discs for your computer from the
HP website. For U.S. support, go to
http://www.hp.com/go/contactHP. For worldwide support,
go to
http://welcome.hp.com/country/us/en/wwcontact_us.html. If you use an external optical
drive, it must be connected directly to a USB port on the computer; the drive cannot be connected
to a USB port on an external device, such as a USB hub.
Be sure that the computer is connected to AC power before you begin creating the recovery
media.
The creation process can take up to an hour or more. Do not interrupt the creation process.
If necessary, you can exit the program before you have finished creating all of the recovery DVDs.
HP Recovery Manager will finish burning the current DVD. The next time you start HP Recovery
Manager, you will be prompted to continue, and the remaining discs will be burned.
To create HP Recovery media:
1. From the Start screen, type recovery, and then select HP Recovery Manager.
2. Select Recovery Media Creation, and then follow the on-screen instructions.
If you ever need to recover the system, see
Recovering using HP Recovery Manager on page 100.
ENWW
Creating recovery media and backups
97

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Pavilion g4 and is the answer not in the manual?

HP Pavilion g4 Specifications

General IconGeneral
Bus typeDMI
SteppingJ1
Tjunction85 °C
Processor cache3 MB
Processor cores2
Processor modeli3-2350M
System bus rate5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-2300 Mobile Series
Processor socketSocket 988
Processor threads4
Processor codenameSandy Bridge
Processor frequency2.3 GHz
Processor cache typeL3
Processor lithography32 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)23
Maximum number of PCI Express lanes16
Motherboard chipset-
Internal memory4 GB
Internal memory typeDDR3-SDRAM
Maximum internal memory8 GB
Memory layout (slots x size)1 x 4 GB
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Card reader integratedYes
Total storage capacity500 GB
Compatible memory cardsMMC, SD
Number of HDDs installed1
HD typeNot supported
Display surfaceGloss
Display diagonal14 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
On-board graphics card ID0x116
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 3000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1150 MHz
Audio systemDolby Advanced Audio v2
Speakers manufacturerAltec Lansing
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates10, 100 Mbit/s
Charging port typeDC-in jack
Headphone connectivity3.5 mm
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity0
Pointing deviceTouchpad
Operating system installedWindows 7 Home Basic
Form factorClamshell
Product typeLaptop
Product colorBlack
Country of originChina
Processor codeSR0DN
Processor ARK ID53438
Processor package size37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Battery capacity47 Wh
Battery life (max)- h
Number of battery cells6
AC adapter power65 W
Weight and Dimensions IconWeight and Dimensions
Depth230.4 mm
Width347 mm
Weight2190 g
Height (rear)35.9 mm
Height (front)30 mm
