NOTE: Before you back up your information, be sure you have designated a location to save the
backup files.
1. Click the System menu icon at the far right of the top panel, and then click System Settings
> Backup icon.
2. Select Folders from the panel on the left side of the window, and beneath Folders to back up,
select the folders to back up.
3. Select Storage from the panel on the left side of the window, click the down-arrow next to
Backup Location, and select Ubuntu One from the drop-down list.
4. Select Overview from the panel on the left side of the window, and then click Back Up Now.
NOTE: The first time you back up your files to Ubuntu One, you will need to create an account
to sign into Ubuntu One. Enter your email address and password into the account sign-in boxes
and follow the on-screen instructions to complete the sign-in process.
To restore backup files:
1. Click the System menu icon at the far right of the top panel, and then click System Settings
> Backup icon.
2.
Click Restore, select the location of the backup files and the folder name, and then click
Forward.
3. Under Restore from When?, select the date of the files to be restored, and then click
Forward.
4. Select the location and folder where the files are to be restored, and then click Forward.
5. Follow the instructions on the screen.
6. Click Restore to start restoring the files, or click Cancel to cancel the operation.
NOTE: You may also back up to cloud storage services provided by various companies. For a small
fee, they will keep your backup for you. A cloud service is recommended, since it is an easy way to
keep your backups off-site and safe.
ENWW
Backing up your information
105

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Pavilion g4 and is the answer not in the manual?

HP Pavilion g4 Specifications

General IconGeneral
Bus typeDMI
SteppingJ1
Tjunction85 °C
Processor cache3 MB
Processor cores2
Processor modeli3-2350M
System bus rate5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-2300 Mobile Series
Processor socketSocket 988
Processor threads4
Processor codenameSandy Bridge
Processor frequency2.3 GHz
Processor cache typeL3
Processor lithography32 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)23
Maximum number of PCI Express lanes16
Motherboard chipset-
Internal memory4 GB
Internal memory typeDDR3-SDRAM
Maximum internal memory8 GB
Memory layout (slots x size)1 x 4 GB
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Card reader integratedYes
Total storage capacity500 GB
Compatible memory cardsMMC, SD
Number of HDDs installed1
HD typeNot supported
Display surfaceGloss
Display diagonal14 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
On-board graphics card ID0x116
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 3000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1150 MHz
Audio systemDolby Advanced Audio v2
Speakers manufacturerAltec Lansing
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates10, 100 Mbit/s
Charging port typeDC-in jack
Headphone connectivity3.5 mm
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity0
Pointing deviceTouchpad
Operating system installedWindows 7 Home Basic
Form factorClamshell
Product typeLaptop
Product colorBlack
Country of originChina
Processor codeSR0DN
Processor ARK ID53438
Processor package size37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Battery capacity47 Wh
Battery life (max)- h
Number of battery cells6
AC adapter power65 W
Weight and Dimensions IconWeight and Dimensions
Depth230.4 mm
Width347 mm
Weight2190 g
Height (rear)35.9 mm
Height (front)30 mm
