HP Pavilion g4 User Manual

Category Description
External media card HP Multi-Format Digital Media Reader slot with push-push technology, supporting
the following digital card formats:
●
Secure Digital (SD) Memory Card
●
Secure Digital High Capacity (SDHC) Memory Card
●
Secure Digital Extended Capacity (SDXC) Memory Card
●
MultiMediaCard (MMC)
Internal media card One half-size Mini Card slot for WLAN
Ports
●
Audio-in (digital microphone)
●
Audio-out (stereo headphone)
●
HDMI version 1.4 supporting up to 1920×1200 @ 60Hz, 24 bits per pixel (bpp)
●
HP Smart Pin AC power adapter
●
RJ-45 (Ethernet, includes link and activity lights)
●
USB 3.0 (two ports)
●
USB 2.0 (one port)
●
VGA (Dsub 15 pin) supporting:
◦
up to 1920 x 1600 external resolution @ 60Hz
◦
Hot plug and unplug and auto-detection for correct output to wide-aspect versus
standard aspect video
Keyboard/pointing devices
●
Full-size, textured, island-style black keyboard
●
Full-size, 3-coat paint, island-style white keyboard
TouchPad with two buttons:
●
Multitouch gesture support enabled as default
●
Taps enabled by default
●
Supports edge-swipe gestures
Power requirements HP Smart AC adapter:
●
90 W RC V HP Smart AC adapter with localized cable plug support (3-wire plug
with ground pin, supports 3-pin DC connector) (for computer models equipped with a
graphics subsystem with switchable discrete memory only)
●
65 W RC V HP Smart AC adapter with localized cable plug support (3-wire plug
with ground pin, supports 3-pin DC connector) (for computer models equipped with a
graphics subsystem with UMA memory only)
Support for the following batteries:
●
6 cell, 47 Whr, 2.20 Ah, Li-ion battery
●
6 cell, 55 Whr, 2.55 Ah, Li-ion battery (select models only)
Supports fast charge
Security Security cable slot
4 Chapter 1 Product description ENWW

HP Pavilion g4 Specifications

General

Bus type	DMI
Stepping	J1
Tjunction	85 °C
Processor cache	3 MB
Processor cores	2
Processor model	i3-2350M
System bus rate	5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-2300 Mobile Series
Processor socket	Socket 988
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.3 GHz
Processor cache type	L3
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	23
Maximum number of PCI Express lanes	16
Motherboard chipset	-
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 4 GB
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
HD type	Not supported
Display surface	Gloss
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x116
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1150 MHz
Audio system	Dolby Advanced Audio v2
Speakers manufacturer	Altec Lansing
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Home Basic
Form factor	Clamshell
Product type	Laptop
Product color	Black
Country of origin	China
Processor code	SR0DN
Processor ARK ID	53438
Processor package size	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery capacity	47 Wh
Battery life (max)	- h
Number of battery cells	6
AC adapter power	65 W

Weight and Dimensions

Depth	230.4 mm
Width	347 mm
Weight	2190 g
Height (rear)	35.9 mm
Height (front)	30 mm
