HP Pavilion g4 User Manual

Item Component Spare part number
(1) 35.6 cm (14.0 in), high definition (HD), LED, SVA, BrightView display assembly (includes webcam,
microphone, wireless antenna transceivers and cable, and display cable):
Supports HD and VGA:
●
Bright purple (modern mesh pattern) 683844-001
●
Ruby red (modern mesh pattern) 683845-001
●
Sparkling black 683847-001
●
Linen white (butterfly blossom pattern) 689462-001
Supports HD Only:
●
Linen white (modern mesh pattern) 707892-001
●
Bright purple (modern mesh pattern) 707888-001
●
Ruby red (modern mesh pattern) 707889-001
●
Winter blue (modern mesh pattern) 707890-001
●
Sparkling black 707891-001
NOTE: For more display assembly spare part information, see
Display assembly subcomponents on page 23.
(2) Keyboard (includes keyboard cable):
Keyboard with black finish:
●
For use in Brazil 698188-201
●
For use in Canada 698188-DB1
●
For use in Japan 698188-291
●
For use in Latin America 698188-161
●
For use in Taiwan 698188-AB1
●
For use in Thailand 698188-281
●
For use in the United States 698188-001
Keyboard with white finish:
●
For use in Latin America 698189-161
(3) Top cover (includes TouchPad):
●
Bright purple (modern mesh pattern) 680573-001
●
Linen white (modern mesh pattern) 684474-001
●
Ruby red (modern mesh pattern) 680574-001
●
Sparkling black 680576-001
●
Winter blue (modern mesh pattern) 680575-001
(4) Power button board (includes cable) 680560-001
(5) TouchPad LED board (includes cable) 683848-001
20 Chapter 3 Illustrated parts catalog ENWW

HP Pavilion g4 Specifications

General

Bus type	DMI
Stepping	J1
Tjunction	85 °C
Processor cache	3 MB
Processor cores	2
Processor model	i3-2350M
System bus rate	5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-2300 Mobile Series
Processor socket	Socket 988
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.3 GHz
Processor cache type	L3
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	23
Maximum number of PCI Express lanes	16
Motherboard chipset	-
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 4 GB
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
HD type	Not supported
Display surface	Gloss
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x116
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1150 MHz
Audio system	Dolby Advanced Audio v2
Speakers manufacturer	Altec Lansing
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Home Basic
Form factor	Clamshell
Product type	Laptop
Product color	Black
Country of origin	China
Processor code	SR0DN
Processor ARK ID	53438
Processor package size	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery capacity	47 Wh
Battery life (max)	- h
Number of battery cells	6
AC adapter power	65 W

Weight and Dimensions

Depth	230.4 mm
Width	347 mm
Weight	2190 g
Height (rear)	35.9 mm
Height (front)	30 mm
