Item Component Spare part number
●
AMD A6-4400M processor (3.2 GHz/2.7 GHz, 1600 MHz/1.0 MB L2 cache,
DDR3, dual core, 35W)
683047-001
●
AMD A4-4300M processor (3.0 GHz/2.5 GHz, 1600 MHz/1.0 MB L2 cache,
DDR3, dual core, 35W)
685990-001
(11) RTC battery 637193-001
(12) Fan and heat sink (includes replacement thermal material):
●
Heat sink for use only with computer models equipped with switchable discrete video
memory
683028-001
●
Heat sink for use only with computer models equipped with UMA video memory 683027-001
●
Heat sink for use only with computer models equipped with AMD E2-1800
processors
697248-001
●
Fan 680551-001
(13) Power connector (includes cable) 680548-001
(14) USB board (includes cable) 680558-001
(15) Optical drive cable (includes optical drive connector) 680546-001
(16) Battery:
●
6 cell, 47 Whr, 2.20 Ah, Li-ion battery 593553-001
●
6 cell, 55 Whr, 2.55 Ah, Li-ion battery (select models only) 593554-001
(17) Base enclosure:
●
Base enclosure Windows 8 707887-001
●
Base enclosure 680544-001
Rubber Feet Kit (not illustrated, includes four rubber feet) 680563-001
(18) Hard drive SATA, does not include hard drive bumpers, bracket, or cable:
9.5 mm (0.37 in) × 6.35 cm (2.50 in):
●
1 TB, 5400 rpm 676521-001
●
750 GB, 7200 rpm 633252-001
●
750 GB, 5400 rpm 634250-001
●
640 GB, 5400 rpm 669300-001
●
500 GB, 7200 rpm 634925-001
●
500 GB, 5400 rpm 669299-001
7.0 mm (0.28 in) × 6.35 cm (2.50 in):
●
320 GB, 5400 rpm 645193-001
Hard Drive Hardware Kit not illustrated, (includes hard drive bracket and bracket
screws, cable, and two bumpers)
682745-001
22 Chapter 3 Illustrated parts catalog ENWW
