HP PoE User Manual

Planning
Planning Your PoE Configuration
With an HP 600 RPS/EPS Powering Two Modules
In this example there are two modules connected to the HP 600 RPS/EPS,
therefore each module will be supplied with 184 watts of PoE power to be
distributed to each modules 24 ports at 7.6 watts per port.
Planning









 
 





Source of
Power
Watts
Available
# of Ports Powered and
Average Watts/Port
Redundant # of Ports
Powered and Average Watts/
Port
External PoE
Power
Supply
184/each
module
24 @ average 7.6 W each None
3-9

HP PoE Specifications

General

Ports	Varies by model
PoE Standard	IEEE 802.3af/at
Total PoE Power Budget	Varies by model
Switching Capacity	Varies by model
Forwarding Rate	Varies by model
Management	CLI
Layer	Layer 2/3
Mounting	Rack-mountable
