HP Pro 3010
System board connectors are color-coded to make it easier to find the proper connection.
Connector Name Connector Color Description
Not labeled white Power supply, 24-pin
ATX_CPU white Power supply, 4-pin
CHASSIS_FAN1 maroon Chassis fan
CPU_FAN white Heat sink fan
J_AUDIO yellow Front I/O audio
J_USB1 white Front I/O USB
F_PANEL black Power button
JUSB2 white Media card reader
SATA0 dark blue Primary hard drive
SATA1 white Primary optical drive
SATA2 light blue Second hard drive
SATA3 orange Second optical drive
Cable Management 51
