CAUTION: Some Startup Repair options will completely erase and reformat the hard drive. All files
you have created and any software installed on the computer are permanently removed. When
reformatting is complete, the recovery process restores the operating system, as well as the drivers,
software, and utilities from the backup used for recovery.
1. If possible, back up all personal files.
2. If possible, check for the presence of the Recovery Image partition and the Windows partition.
From the Start screen, type file, and then click File Explorer.
– or –
From the Start screen, type pc, and then select This PC.
NOTE: If the Windows partition and the Recovery Image partition are not listed, you must
recover your operating system and programs using the Windows operating system DVD and the
Driver Recovery media (both purchased separately). For additional information, see Using
Windows operating system media (purchased separately) on page 70.
3. If the Windows partition and the Recovery Image partition are listed, restart the computer by
pressing and holding the shift key while clicking Restart.
4. Select Troubleshoot, then select Advanced Options, and then select Startup Repair.
5. Follow the on-screen instructions.
NOTE: For additional information on recovering information using the Windows tools, perform a
search for these topics in Windows Help and Support.
Using f11 recovery tools
CAUTION: Using f11 completely erases hard drive contents and reformats the hard drive. All files
that you have created and any software that you have installed on the computer are permanently
removed. The f11 recovery tool reinstalls the operating system and HP programs and drivers that
were installed at the factory. Software not installed at the factory must be reinstalled.
To recover the original hard drive image using f11:
1. If possible, back up all personal files.
2. If possible, check for the presence of the Recovery Image partition: From the Start screen, type
pc, and then select This PC.
NOTE: If the Recovery Image partition is not listed, you must recover your operating system
and programs using the Windows operating system media and the
Driver Recovery media (both
purchased separately). For additional information, see
Using Windows operating system media
(purchased separately) on page 70.
3. If the Recovery Image partition is listed, restart the computer, and then press esc while the
“Press the ESC key for Startup Menu” message is displayed at the bottom of the screen.
4. Press f11 while the “Press <F11> for recovery” message is displayed on the screen.
5. Follow the on-screen instructions.
Performing a system recovery 69

HP ProBook 430 G2 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Grey
Country of origin	China
Bus type	DMI2
Stepping	D0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-4210U
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4200 Mobile series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Haswell
Processor frequency	1.7 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.7 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	4x1, 2x4
Thermal Design Power (TDP)	15 W
Maximum number of PCI Express lanes	12
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA
Storage media	SSD
Card reader integrated	Yes
Total storage capacity	128 GB
Number of SSDs installed	1
Display diagonal	13.3 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0xA16
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4400
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	200 MHz
On-board graphics card dynamic frequency (max)	1000 MHz
Intel segment tagging	Enterprise, Professional
Audio system	DTS Sound+
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
DisplayPorts quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pointing device	Touchpad
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Processor code	SR1EF
Processor ARK ID	81016
Intel TSX-NI version	0.00
Processor package size	40 x 24 x 1.5 mm
Intel ME Firmware Version	9.5
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Smart Connect Technology version	1.00
Battery capacity	44 Wh
Battery life (max)	- h

Weight and Dimensions

Depth	233.5 mm
Width	326 mm
Weight	1500 g
Height (rear)	21 mm
Height (front)	20 mm
