Table 3-2 Display component descriptions and part numbers (continued)
Item Component Spare part number
(3) Display panel
FHD, privacy, 1000 nits M23952-001
FHD, 400 nits M21390-001
FHD, 250 nits M21389-001
FHD, 250 nits, Touch-on Panel (TOP) M21391-001
HD, 250 nits M21392-001
LCD Support Kit (includes display panel adhesive and bezel adhesive; not illustrated) M23559-001
(4) Hinges (left and right; includes bezel trim pieces, bezel trim protective shielding, display panel
adhesive, and bezel adhesive)
M21374-001
(5) WLAN antennas and cables (includes display panel adhesive and bezel adhesive) M23850-001
(6) Display/camera cable (includes display panel adhesive and bezel adhesive) M23766-001
(7) Display back cover (includes bezel adhesive)
WWAN, 250 nit models M21383-001
WLAN, 400 nit models M21384-001
(8) WWAN antennas and cables (includes display panel adhesive and bezel adhesive) M23851-001
(9) WWAN cable (included in the display cable kit) M23766-001
Cable Kit
To identify the contents of the Cable Kit, use this table.
Table
3-3 Cable Kit content descriptions and part number
Component Spare part number
Cable Kit, includes: M23765-001
I/O board cable
I/O board cable (USB 3.0)
Touchpad cable
Fingerprint reader board cable
Miscellaneous parts
To identify the miscellaneous parts, use this table.
Table
3-4 Miscellaneous part descriptions and part numbers
Component Spare part number
AC adapters
22 Chapter 3 Illustrated parts catalog
