Hard drive

Table 5-6 Hard drive description and part number

Description Spare part number

Hard drive, 1 TB, 5400 rpm, 7 mm L30422-001

Hard drive, 500 GB, 7200 rpm, 7 mm 703267-001

Hard Drive Hardware Kit (includes hard drive cover and connector) L44510-001

Before removing the hard drive, follow these steps:

1. Prepare the computer for disassembly (Preparation for disassembly on page 34).

2. Place the computer in “Battery Safe mode” (Battery Safe mode on page 34).

3. Remove the bottom cover (Bottom cover on page 35).

4. Remove the battery (Battery on page 36).

Remove the hard drive:

1. Release the ZIF connector (1), and then disconnect the hard drive cable from the system board (2).

2. Remove the two Phillips M2.0 × 4.0 screws (3) that secure the hard drive to the computer.

3. Use the tab to lift the hard drive from the bay (4).

Component replacement procedures 41
