HP ProBook 4525s Service Manual

Category Description HP ProBook
4525s UMA
HP ProBook
4525s discrete
Graphics AMD Universal Memory Architecture (UMA) graphics
subsystem integrated with shared video memory
(dynamically allocated) (ATI Mobility Radeon HD
4250)
√
AMD Discrete Graphics ATI M93S3-LP with
Hypermemory support. 512MB DDR3, 800MHz (ATI
Mobility Radeon HD530v configurable via base unit)
√
AMD Discrete Graphics ATI Park-XT S3/M2 with
Hypermemory support. 512MB DDR3, 800MHz (ATI
Mobility Radeon HD5470 configurable via base unit)
√
Panels All display assemblies support privacy filter √√
15.6-in HD LED backlight panel:
●
1366×768 AntiGlare
●
1366×768 AntiGlare for webcam
●
1366×768 BrightView
●
1366×768 BrightView for webcam
√√
15.6-in HD LED backlight panel (optional):
●
1366×768 AntiGlare for webcam and WWAN
●
1366×768 BrightView for webcam and WWAN
√
Memory 2 customer-accessible/upgradable memory module
slots
√√
Supports dual-channel memory √√
Supports up to 8 GB of system RAM √√
PC3-1066, 1333-MHz, DDR3 √√
Supports the following configurations in all countries
and regions:
●
8192-MB total system memory (4096-MB × 2,
dual-channel)
●
4096-MB total system memory (4096-MB × 1)
●
4096-MB total system memory (2048-MB × 2,
dual-channel)
●
3072-MB total system memory (2048-MB +
1024-MB, dual-channel)
●
2048-MB total system memory (2048-MB × 1)
●
2048-MB total system memory (1024-MB × 2,
dual-channel)
●
1024-MB total system memory (1024-MB × 1)
√√
Hard drives Supports 9.5- and 12.7-mm, 6.35-cm (2.50-in) hard
drives
√√
Customer-accessible √√
2 Chapter 1 Product description

HP ProBook 4525s Specifications

General

Graphics	ATI Mobility Radeon HD 4250
Processor	AMD Turion II, AMD Athlon II
Display	15.6-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
Memory	Up to 8 GB DDR3
Storage	250GB, 320GB, 500GB HDD
Operating System	Genuine Windows 7 Professional, Genuine Windows 7 Home Premium, Genuine Windows 7 Home Basic
Battery	6-cell Lithium-Ion
Chipset	AMD M880G
Optical Drive	DVD+/-RW SuperMulti DL
Wireless	802.11b/g/n, Bluetooth 2.1
Audio	Integrated stereo speakers, Integrated microphone
Ports	3 USB 2.0, VGA, HDMI, RJ-45, headphone/microphone combo jack
Card Reader	SD/MMC
Webcam	2 MP Webcam
