HP ProBook 4525s Service Manual

Category Description HP ProBook
4525s UMA
HP ProBook
4525s discrete
Serial ATA √√
Supports the following 9.5-mm drives:
●
750-GB, 5400-rpm
●
640-GB, 5400-rpm
●
500-GB, 7200-rpm
●
320-GB, 7200-rpm
●
250-GB, 7200-rpm
√√
Supports the following 12.7-mm drive:
●
750-GB, 5400-rpm
√√
HP 3D DriveGuard (not available on Linux) √√
Optical drives Fixed, no modular requirements √√
SATA 12.7-mm tray load √√
Supports option of no optical drive √√
Supports the following drives:
●
DVD-ROM Drive
●
DVD±RW SuperMulti Double-Layer Combo
Drive with Lightscribe
●
Blu-ray ROM DVD±RW SuperMulti DL Drive
(not available with UMA base unit and Windows
XP)
√√
Diskette drive Supports external USB diskette drive only √√
Audio/visual IDT 92HD80 √√
Integrated microphone √√
Stereo speakers (2) √√
Integrated 2MP camera with fixed focus (select
models only)
√√
Headphone and microphone jacks √√
Modem High-speed 56K modem for all regions and countries
except APJ
√√
High-speed 56K modem APJ only √√
Modem cable not included √√
Supports no modem option √√
Ethernet 10/100/1000 Ethernet network interface card (NIC) √√
S3/S4/S5 wake on LAN: AC only mode √√
Wireless Integrated WLAN options by way of MiniPCI card:
2 WLAN antennas built into display assembly √√
3

HP ProBook 4525s Specifications

General

Graphics	ATI Mobility Radeon HD 4250
Processor	AMD Turion II, AMD Athlon II
Display	15.6-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
Memory	Up to 8 GB DDR3
Storage	250GB, 320GB, 500GB HDD
Operating System	Genuine Windows 7 Professional, Genuine Windows 7 Home Premium, Genuine Windows 7 Home Basic
Battery	6-cell Lithium-Ion
Chipset	AMD M880G
Optical Drive	DVD+/-RW SuperMulti DL
Wireless	802.11b/g/n, Bluetooth 2.1
Audio	Integrated stereo speakers, Integrated microphone
Ports	3 USB 2.0, VGA, HDMI, RJ-45, headphone/microphone combo jack
Card Reader	SD/MMC
Webcam	2 MP Webcam
