Item Description Spare part number
(1) Display panel assembly, 35.6-cm (14.0-inch)
Non-touch displays are ONLY spared at the subcomponent level. For more information about
display components, see Display components on page 21.
(2) Keyboard (includes cable)
NOTE: For a detailed list of keyboard country codes, see Keyboard on page 43.
No backlight 827028-xxx
Backlit 827029-xxx
(3) Top cover (includes touchpad assembly) 828402-001
(4) Card reader board 828416-001
(5) Power button board 827035-001
(6) Function board 828419-001
(7) USB/audio board 827032-001
(8) Fingerprint reader assembly (includes cable and bracket) 828417-001
(9) Speaker assembly 828420-001
(10) RTC battery 826388-001
(11) Power connector cable 827039-001
(12) System board (includes replacement thermal material)
All system boards use the following part numbers:
xxxxxx-001: Windows 7 or non-Windows operating systems
xxxxxx-601: Windows 8.1 or Windows 10 operating system
Models with 2 GB of discrete graphics memory:
●
AMD A10-8700P processor 828433-xxx
●
AMD A8-7410 processor 828434-xxx
●
AMD A4-7210 processor 828436-xxx
Models with UMA graphics memory:
●
AMD A10-8700P processor 828431-xxx
●
AMD A8-7410 processor 828432-xxx
●
AMD A4-7210 processor 828435-xxx
(13) Battery connector 828418-001 (Cable Kit)
Heat sink assembly (includes replacement thermal material)
(14) For use in models with UMA graphics 830933-001
(15) For use in models with discrete graphics 828409-001
(16) Fan 827040-001
(17) Base enclosure 828410-001
(18) Battery, Li-ion
Computer major components 19
