Item Description Spare part number
(1) Display panel assembly, 35.6-cm (14.0-inch)
Displays are ONLY spared at the subcomponent level. For more information about display
components, see Display components on page 19.
(2) Keyboard (includes cable)
NOTE: For a detailed list of keyboard country codes, see Keyboard on page 43.
No backlight 827028-xxx
Backlit 827029-xxx
(3) Top cover (includes touchpad assembly) 827036-001
(4) Power button board 827035-001
(5) Function board 827033-001
(6) USB/audio board 827032-001
(7) Card reader board 827034-001
(8) Power connector cable 827039-001
(9) Fingerprint reader assembly (includes cable and bracket) 827054-001
(10) Speaker assembly 827037-001
(11) Battery connector 827031-001 (Cable Kit)
(12) Optical drive cable and connector not spared
(13) Fan 827040-001
(14) System board (includes replacement thermal material)
All system boards use the following part numbers:
xxxxxx-001: Windows 7 or non-Windows operating systems
xxxxxx-601: Windows 8.1 or Windows 10 operating system
Intel Core i7-6500U processor; 2-GB discrete graphics memory 827026-xxx
Intel Core i5-6200U processor; 2-GB discrete graphics memory 827025-xxx
Intel Core i5-6200U processor; 1-GB discrete graphics memory 827023-xxx
Intel Core i3-6100U processor; 2-GB discrete graphics memory 827024-xxx
Intel Core i3-6100U processor; 1-GB discrete graphics memory 827022-xxx
(15) Heat sink assembly (for discrete graphics; includes replacement thermal material) 828396-001
(16) RTC battery 826388-001
(17) Memory modules (PC3L-12800, 1600-MHz, DDR3L)
8-GB 670034-001
4-GB 641369-001
2-GB 652972-001
(18) Base enclosure 827051-001
(19) Hard drive
Computer major components 17
