Item Description Spare part number
2 TB, 5400 rpm, 9.5 mm 801808-001
1 TB, 5400 rpm, 7 mm 778192-001
500 GB, 5400 rpm, 7 mm 778187-001
500 GB, 5400 rpm, 7 mm, hybrid (8-GB SSD) 732000-001
500 GB, 7200 rpm, 7 mm 634920-001
(20) Hard drive Hardware Kit (includes bracket and screws) 828147-001
(21) Optical drives
Blu-ray Disc R/RW with SuperMulti Drive 827018-001
DVD+/-RW Double-Layer SuperMulti Drive 827020-001
DVD-ROM Drive 827019-001
(22) WLAN module
Realtek RTL8188EE 802.11b/g/n 1x1 Wi-Fi Adapter (Worldwide) 792609-001
Realtek RTL8723BE 802.11b/g/n 1x1 Wi-Fi + BT4.0 Combo Adapter (Worldwide) 792610-001
Realtek RTL8723BE bgn 1x1 + BT 4 LE PCIe+USB NGFF 2230 M.2 (Worldwide) 792611-001
Broadcom 943228 abgn 2x2 + BT 4 LE PCIe+USB NGFF 2230 MOW (Most of World) 797884-001
7260NGW Intel Dual Band Wireless-AC 7260 802.11ac, Dual Band, 2x2 Wi-Fi + Bluetooth 4.0 806722-001
Intel Dual Band Wireless-AC 3165 802.11ac, Dual Band, 1×1 Wi-Fi + Bluetooth 4.0 (Most of World) 806723-001
(23) Solid-state drive, M.2
256-GB, TLC 827583-001
128-GB, TLC 827053-001
(24) Battery, Li-ion
6-cell, 55 WHr, 2.8 Ah 811346-001
4-cell, 44 WHr, 3.0 Ah 805294-001
Plastics Kit, includes: 829013-001
(25) Large service door
(26) Small service door
Fingerprint reader insert (for models without a ngerprint reader)(not illustrated)
18 Chapter 3 Illustrated parts catalog
