Table 3-1 Computer major component descriptions and part numbers
Item Component Spare part number
(1) Display assembly
250 nits, with HD camera M03425-001
250 nits, with HD + IR camera M03426-001
400 nits, with HD camera M03427-001
400 nits, with HD + IR camera M03428-001
1000 nits, with HD camera, privacy M03429-001
1000 nits, with HD + IR camera, privacy M03430-001
(2) Keyboard/top cover
For a detailed list of country codes, see Keyboard with top cover on page 50.
For models without a rear camera, backlit M03444-xx1
For models with a rear camera, backlit M03445-xx1
For models without a rear camera, backlit M03446-xx1
For models with a rear camera, backlit M03447-xx1
For models without a rear camera, not backlit M03448-xx1
For models with a rear camera, not backlit M03449-xx1
(3) Touchpad
NOTE: The touchpad cable is available in the Cable Kit, spare part number M03431-001.
M03435-001
(4) Power connector cable M03424-001
(5) Speaker M03439-001
(6) Rear camera board (included in Camera Module Kit) M03443-001
(7) Rear camera module (included in Camera Module Kit) M03443-001
(8) Fingerprint sensor (includes gasket)
NOTE: The ngerprint sensor cable is available in the Cable Kit, spare part number M03431-001.
M03434-001
(9) RTC battery L13694-001
(10) System board (includes integrated processor)
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating system
xxxxxx-601: Windows 10 operating system
AMD Ryzen 7-4750U processor M09344-xx1
AMD Ryzen 7-4700U processor M03442-xx1
AMD Ryzen 5-4650U processor M09343-xx1
AMD Ryzen 5-4500U processor M03441-xx1
AMD Ryzen 3-4300U processor M03440-xx1
(11) Heat sink M03433-001
18 Chapter 3 Illustrated parts catalog
