HP ProCurve Switch 1700 Series
3
Specifications
HP ProCurve Switch 1700-24 (J9080A) HP ProCurve Switch 1700-8 (J9079A)
Ports
22 auto-sensing 10/100 ports (IEEE 802.3 Type 10Base-T, IEEE
802.3u Type 100Base-TX); Media Type: Auto-MDIX; Duplex: half or
full
7 auto-sensing 10/100 ports (IEEE 802.3 Type 10Base-T, IEEE
802.3u Type 100Base-TX); Media Type: Auto-MDIX; Duplex: half or
full
2 dual-personality ports; each port can be used as either an RJ-45
10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type
100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or an
open mini-GBIC slot (for use with mini-GBIC transceivers)
1 auto-sensing 10/100/1000 port (IEEE 802.3 Type 10Base-T, IEEE
802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T); Media
Type: Auto-MDIX; Duplex: 10Base-T/100Base-TX: half or full;
1000Base-T: full only
Physical characteristics
Dimensions
6.74(d) x 17.42(w) x 1.73(h) in. (17.12 x 44.25 x 4.39 cm) (1U height) 4.58(d) x 7.73(w) x 1.73(h) in. (11.63 x 19.63 x 4.39 cm) (1U height)
Weight
4.38 lb. (1.99 kg) 1.19 lb. (0.54 kg)
Memory and processor
2 MB flash, 2 MB RAM/ROM capacity; packet buffer size: 500 KB 1 MB flash, 1 MB RAM/ROM capacity; packet buffer size: 144 KB
Mounting
Mounts in an EIA-standard 19 in. telco racks (hardware included) Horizontal surface mounting only
Performance
100 Mb Latency
< 4.7 µs (64-byte packets) < 3.9 µs (64-byte packets)
1000 Mb Latency
< 3.0 µs (64-byte packets) < 2.1 µs (64-byte packets)
Throughput
up to 6.2 million pps (64-byte packets) up to 2.0 million pps (64-byte packets)
Switching capacity
8.4 Gbps 3.4 Gbps
MAC address table size
8000 entries 8000 entries
Environment
Operating temperature
32ºF to 104ºF (0ºC to 40ºC) 32ºF to 104ºF (0ºC to 40ºC)
Operating relative humidity
15% to 95% @ 104ºF (40ºC), non-condensing 15% to 95% @ 104ºF (40ºC), non-condensing
Non-operating/Storage temperature
-40ºF to 158ºF (-40ºC to 70ºC) -40ºF to 158ºF (-40ºC to 70ºC)
Non-operating/Storage relative humidity
10% to 90% @ 149ºF (65ºC), non-condensing 10% to 90% @ 149ºF (65ºC), non-condensing
Altitude
up to 10000 ft. (3 km) up to 10000 ft. (3 km)
Acoustic
Power: 0 dB No Fan Power: 0 dB No Fan
Electrical characteristics
Maximum heat dissipation
82 BTU/hr (87 kJ/hr) 61 BTU/hr (64 kJ/hr)
Voltage
100-127 / 200-240 VAC 100-127 / 200-240 VAC
