4
HP ProCurve 1810G Switch Series
Specifications
HP ProCurve 1810G-24 Switch (J9450A) HP ProCurve 1810G-8 Switch (J9449A)
Ports 22 auto-sensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T, IEEE
802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T); Media Type:
Auto-MDIX; Duplex: 10Base-T/100Base-TX: half or full; 1000Base-T: full only
2 dual-personality ports; each port can be used as either an RJ-45
10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type
100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or an open
mini-GBIC slot (for use with mini-GBIC transceivers)
8 auto-sensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T, IEEE
802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T); Media Type:
Auto-MDIX; Duplex: 10Base-T/100Base-TX: half or full; 1000Base-T: full only
Physical characteristics
Dimensions
Weight
17.12(d) x 44.25 (w) x 4.39 (h) cm (6.74 x 17.42 x 1.73 in.) (1U height)
1.96 kg. (4.32 lb), Fully loaded
11.63(d) x 19.63(w) x 4.39(h) cm (4.58 x 7.73 x 1.73 in.) (1U height)
0.54 kg (1.19 lb.), Fully loaded
Memory and processor 8 MB flash, 16 MB SDRAM; packet buffer size: 512 KB 8 MB flash, 16 MB SDRAM; packet buffer size: 512 KB
Mounting Mounts in an EIA-standard 19 in. telco rack (hardware included); wall,
desktop, tabletop and undertable mounting
Wall, ceiling, desktop, and undertable mounting
Performance
100 Mb Latency
1000 Mb Latency
Throughput
Switching capacity
MAC address table size
< 4.7 µs (64-byte packets)
< 3.0 µs (64-byte packets)
up to 35.7 million pps (64-byte packets)
48 Gbps
8,000 entries
< 3.9 µs (64-byte packets)
< 2.1 µs (64-byte packets)
up to 11.9 million pps (64-byte packets)
16 Gbps
8,000 entries
Environment
Operating temperature
Operating relative humidity
Non-operating/Storage temperature
Non-operating/Storage relative humidity
Altitude
Acoustic
0ºC to 40ºC (32ºF to 104ºF)
15% to 95% @ 40ºC (104ºF), non-condensing
-40ºC to 70ºC (-40ºF to 158ºF)
15% to 90% @ 65ºC (149ºF), non-condensing
up to 3 km (10,000 ft.)
Power: 0 dB no fan
0ºC to 40ºC (32ºF to 104ºF)
15% to 95% @ 40ºC (104ºF), non-condensing
-40ºC to 70ºC (-40ºF to 158ºF)
15% to 90% @ 65ºC (149ºF), non-condensing
up to 3 km (10,000 ft.)
Power: 0 dB no fan
Electrical characteristics
Maximum heat dissipation
Voltage
Current
Maximum power rating
Frequency
Notes
107.61 kJ/hr (102 BTU/hr)
100-127 / 200-240 VAC
0.7 / 0.4 A
30 W
50 / 60 Hz
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
53.81 kJ/hr (51 BTU/hr)
100-240 VAC
0.5 A
15 W
50 / 60 Hz
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
The exact input voltage and frequency rating are determined by the specific
power adapter part number ordered. Please select the correct power
adapter country option.
Safety CSA 22.2 No. 60950; EN 60950/IEC 60950; UL 60950 CSA 22.2 No. 60950; EN 60950/IEC 60950; UL 60950
Emissions FCC Rules Part 15, Subpart B Class A; EN 55022; VCCI; ICES-003
(Canada)
FCC Rules Part 15, Subpart B Class A; EN 55022; VCCI; ICES-003
(Canada)
Immunity
EN
ESD
Radiated
EFT/Burst
Surge
Conducted
Power frequency magnetic field
Voltage dips and interruptions
Harmonics
Flicker
EN 55024, CISPR 24
IEC 61000-4-2
IEC 61000-4-3
IEC 61000-4-4
IEC 61000-4-5
IEC 61000-4-6
IEC 61000-4-8
IEC 61000-4-11
IEC 61000-3-2
IEC 61000-3-3
EN 55024, CISPR 24
IEC 61000-4-2
IEC 61000-4-3
IEC 61000-4-4
IEC 61000-4-5
IEC 61000-4-6
IEC 61000-4-8
IEC 61000-4-11
IEC 61000-3-2
IEC 61000-3-3
Management HP ProCurve Manager; Web browser HP ProCurve Manager; Web browser
Notes Use only supported genuine ProCurve mini-GBICs with your switch. Power: external AC power adapter and IEEE 802.3af-compatible PoE-PD,
class 3 on Port 1
