Quality of Service (QoS): Managing Bandwidth More Effectively

Using QoS Classifiers To Configure Quality of Service for Outbound Traffic

The DSCPs for this

example have not yet

been assigned an

802.1p priority level.

Figure 8-20. Display the Current DSCP-Map Configuration

2. Configure the policies in the DSCP table:

Figure 8-21. Example of Policies Configured (with Optional Names) in the DSCP

Table

8-44
