Access Control Lists (ACLs) for the Series 5300xl Switches
Configuring and Assigning an ACL
A (Refer to figure 9-13, above.)
B (Refer to figure 9-13, above.)
Enabling ip routing activates ACL
operation on routed traffic.
Executing write memory saves the
configuration changes to the
startup-config file.
Figure 9-14. Example of Configuration Commands for an Extended ACL
9-43
