HP ProDesk 400 G1 Specification

Unit Environment and Operating Conditions
General Unit Operating Guidelines
Keep the computer away from excessive moisture, direct moisture and the extremes of heat and cold, to ensure that unit is
operated within the specified operating range.
Leave a 10.2 cm (4 in) clearance on all vented sides of the computer to permit the required airflow.
Never restrict airflow into the computer by blocking any vents or air intakes.
Do not stack computers on top of each other or place computers so near each other that they are subject to each other's re-
circulated or preheated air.
Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint, dust and other foreign
matter can block the vents and limit the airflow.
If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must be provided on the enclosure,
and the same operating guidelines listed above will still apply.
Temperature Range Operating: 50° to 95° F (10° to 35° C) *
Non-operating: –22° to 140° F(–30° to 60° C)
Relative Humidity Operating: 10% to 90% (non-condensing at ambient)
Non-operating: 5% to 95% (non-condensing at ambient)
Maximum Altitude
(unpressurized)
Operating: 10,000 ft (3048 m)
Non-operating: 30,000 ft (9144 m)
*Operating temperature is de-rated 1.0 deg C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea level, no direct sustained sunlight.
Maximum rate of change is 10 deg C/Hr. The upper limit may be limited by the type and number of options installed.
Power Supply
MT SFF
Standard Efficiency 300W active PFC
(230 VAC input only)
240W active PFC
High Efficiency*
80 PLUS Bronze
300W active PFC EStar 6
82/85/82% efficient at 20/50/100%
load (115V)
82/85/82% efficient at 20/50/100%
load (230V)
240W active PFC
82/85/82%efficient at 20/50/100%
load (115V)
82/85/82% efficient at 20/50/100%
load (230V)
Operating Voltage Range 90 - 264 VAC 90 - 264 VAC
Rated Voltage Range 200 - 240 VAC (300W active PFC)
100 - 240 VAC
100 - 240 VAC
Rated Line Frequency 50/60 Hz 50/60 Hz
Operating Line Frequency Range 47 - 63 Hz 47 - 63 Hz
Rated Input Current 4A 4A
Rated Input Current with Energy Efficient * Power
Supply
4A 4A
Current Leakage
(NFPA 99)
<900uA / 230Vac (300W PSU) < 275 µA @ 120V
Power Supply Fan 80mm Fan (300W PSU) 70mm Fan
Power cord length 6.0 ft. (1.83 m) 6.0 ft. (1.83 m)
External Power Adapter
QuickSpecs
HP ProDesk 400 G1 Business Series Desktop
Technical Specifications – Power
DA - 14693 North America — Version 5 — February 13, 2014 Page 51

HP ProDesk 400 G1 Specifications

General

Tcase	72.72 °C
Bus type	DMI2
Stepping	C0
Processor cache	6 MB
Processor cores	4
Processor model	i5-4570
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4500 Desktop Series
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Number of QPI links	0
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	28 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Memory slots	2x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 8 GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	1000 GB
Intel segment tagging	Enterprise, Small Business
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
On-board graphics card ID	0x412
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4600
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Bundled software	HP PageLift\\r HP Support Assistant\\r HP ePrint\\r Acquisto Office\\r Confezione\\r Cyberlink Power DVD, BD\\r CyberLink Power2Go\\r Device Access Manager\\r HP File Sanitizer\\r HP Disk Sanitizer, External Edition\\r HP Password Manager\\r HP Recovery Disk Creator\\r HP Wireless Hotspot\\r Microsoft Defender\\r Microsoft Security Essentials\\r PDF Complete Corporate Edition\\r Skype
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Audio system	Realtek ALC221
Product type	PC
Motherboard chipset	Intel® H81
Password protection type	BIOS
Scalability	1S
Processor code	SR14E
Processor ARK ID	75043
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Graphics & IMC lithography	22 nm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013D
Intel Identity Protection Technology version	1.00
Power supply	300 W
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	402 mm
Width	182.8 mm
Height	357 mm
Weight	7140 g
