Fan
The fan is attached to the rear of the chassis with two Phillips screws.
1. Prepare the computer for disassembly (Preparation for disassembly on page 17).
2. Remove the access panel (Access panel on page 18).
3. From the outside, rear of the chassis, remove the two Phillips screws that secure the fan to the chassis.
4. From inside the chassis, disconnect the fan cable from the system board connector labeled CHFAN (1).
5. Lift the fan out of the chassis (2).
To install the fan, reverse the removal procedures.
Fan 37
