HP ProDesk 400 G3

EL-MF877-00 Page 4
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Figure7 Release the HDD screws
Figure8 Remove the HDD form chassis
Figure9 Push the latch and release the Slim ODD.
Figure10 Remove the Slim ODD form chassis.
Figure11 Unplug all cable conn. from PCA.
Figure12 Release 6 pcs screws from PCA
