8. Slide the system board toward the front of the chassis to disengage the connectors (2), and then
lift the system board up and out of the chassis (3).
To install the system board, reverse the removal procedure.
NOTE: When replacing the system board, you must also change the chassis serial number in the
BIOS.
CAUTION: When reconnecting the cables it is important that they be positioned correctly.
Changing from desktop to tower configuration
The Small Form Factor computer can be used in a tower orientation with an optional tower stand that
can be purchased from HP.
1. Prepare the computer for disassembly (
Preparation for disassembly on page 84).
Changing from desktop to tower configuration
129
