No. System Board Connector System Board Label Color Component
18 SATA 3.0 SATA1 light blue Any SATA Device other than the
Primary Hard Drive
19 SATA 3.0 SATA2 light blue Any SATA Device other than the
Primary Hard Drive
20 USB 2.0 MEDIA black USB 2.0 Device, such as a Media
Card Reader
Drives
Description Spare part number
Optical drives
DVD±RW drive 657958-001
DVD-ROM drive 608394-001
Blu-ray BD-RW SuperMulti XL Drive 719157-001
Hard drives
2 TB, 7200 rpm hard drive 616608-001
1 TB hard drive, hybrid SSD 724937-001
1 TB, 7200 rpm hard drive 613202-001
500 GB, 7200 rpm, 2.5-inch hard drive, self-encrypting (SED) 696442-001
500 GB, 7200 rpm hard drive 613208-001
500 GB hard drive, hybrid SSD 724938-001
256 GB Solid State Drive (SSD), self-encrypting (SED) 680020-001
160 GB Solid State Drive (SSD) 646809-001
128 GB Solid State Drive (SSD) 665961-001
128 GB Solid State Drive (SSD), TCG 728559-001
120 GB Solid State Drive (SSD) 661841-001
Card reader, 14-in-1, USB 3.0, 3.5-inch 716390-001
When installing drives, follow these guidelines:
●
The primary Serial ATA (SATA) hard drive must be connected to the dark blue primary SATA
connector on the system board labeled SATA0.
●
Connect secondary hard drives and optical drives to any of the light blue SATA connectors on the
system board (labeled SATA1, SATA2, and SATA3).
50 Chapter 5 Removal and replacement procedures: Tower (TWR)
