Component identification 63
Component identification
Front panel components
Item Description
1
SUV connector*
2
Serial label pull tab
3
Release button
4
Server blade release lever
5
Power On/Standby button
6
Hard drive bay 1
7
Hard drive bay 2
*The SUV connector and the HP c-Class Blade SUV Cable are for some server blade configuration and diagnostic
procedures.
